1
866067
866067
MAIN WIRING HARNESS
€612,34
2
866068
866068
RH HEADLIGHT
€155,75
3
866069
866069
LH HEADLIGHT
€155,75
4
AP8221242
AP8221242
SPEC. SELF-TAP SCREW 3.5X20
€1,23
5
AP8150177
AP8150177
Washer 5,3X10X1
€0,19
6
580734
580734
Lamp
€50,09
7
866300
866300
FRONT DAYLIGHT RUNNING LIGHT GLASS
€7,90
8
00011030900
00011030900
9
890214
890214
REAR LH TURN INDICATOR
€56,30
10
890213
890213
REAR RH TURN INDICATOR
€56,30
11
00H01701011
00H01701011
LAMP RY10W 12V
AP8127489
AP8127489
LAMP RY10W 12V
€6,46
12
AP8224470
AP8224470
HEX SOCKET SCREW M6X20
€1,23
13
AP8150179
AP8150179
Washer 6,6x18x1,6*
€1,23
14
AP8152299
AP8152299
SELF-LOCKING NUT M6
€1,89
15
865634
865634
Tail lamp
€98,17
16
AP8152351
AP8152351
SCREW 4.2X16
€0,18
17
AP8150501
AP8150501
Washer
€2,58
18
864461
864461
SPACER BUSH
€10,82
19
00D01010821
00D01010821
SILENT-BLOCK
€2,34
20
866007
866007
BATTERY BOX
€20,80
21
AP8150246
AP8150246
SCREW M4.8X13
€4,79
22
AP8150248
AP8150248
Washer 5,5x15x1,6
€0,97
23
AP8144553
AP8144553
SUPPORT RUBBER PART
€32,07
24
00H01803471
00H01803471
VIBRATION-DAMPING RUBBER
€5,00
25
497484
497484
Yuasa battery 12V-4Ah
292330
292330
Yuasa battery 12V-4Ah
€103,27
26
00G01802361
00G01802361
O-ring
€4,11
27
86135R
86135R
Hupe
863339
863339
Hupe
€33,77
28
AP8152285
AP8152285
SCREW W/FLANGE M8X16
€1,89
29
AP8150376
AP8150376
Washer 8,5x15x0,8
€1,71
30
AP8152300
AP8152300
SELF-LOCKING NUT M8
€2,07
31
58115R
58115R
Relay 12V/80A
584521
584521
Relay 12V/80A
€23,16
32
AP8152272
AP8152272
Screw w/ flange M5x12
€1,89
33
00031105000
00031105000
WASHER D5
€1,48
34
AP8102375
AP8102375
CLIP M5
€2,23
35
897642
897642
IGNITION ELECTRONICAL DEVICE
€50,15
36
00G03301271
00G03301271
SPARKPLUG CAP
€25,45
37
00002062011
00002062011
HEX SOCKET SCREW M6X20
AP8150044
AP8150044
HEX SOCKET SCREW M6X20
€1,23
38
00402060001
00402060001
WASHER D6 DIN125 AZNB
€1,23
39
254485
254485
Clip M6
€1,69
40
898891
898891
VOLTAGE REGULATOR
€91,50
41
AP8150137
AP8150137
HEX SOCKET SCREW
€1,22
42
AP8150012
AP8150012
Washer 5,3x10x1*
€3,04
43
00G03301731
00G03301731
INSULATING CAP
231571
231571
INSULATING CAP
€3,55
44
864506
864506
RELAY
€12,67
45
866072
866072
DASHBOARD
€1.108,09
46
AP8152329
AP8152329
Phillips screw, SWP M5x20
€1,89
47
AP8150248
AP8150248
Washer 5,5x15x1,6
€0,97
48
00D01010821
00D01010821
SILENT-BLOCK
€2,34
49
864461
864461
SPACER BUSH
€10,82
50
898626
898626
WHEEL SPEED SENSOR
€89,19
51
AP8120582
AP8120582
CABLE-GUIDE
€6,45
52
AP8120416
AP8120416
BLACK HOSE 178X4
€1,03
53
AP8120657
AP8120657
HOSE CLAMP
€1,89
54
00N05700601
00N05700601
SWITCH
€102,85
55
00H01001911
00H01001911
FUSE 7.5A
00H01000911
00H01000911
FUSE 7.5A
€15,00
56
864565
864565
DIODE
€16,70
57
AP8117003
AP8117003
ADHESIVE SPONGE 15X5
€12,35
58
CM201402
CM201402
PIPE COVER
€1.085,64
59
00G05701471
00G05701471
NUMBER-PLATE LIGHT
€41,94
60
00G02300581
00G02300581
LAMPHOLDER
€35,13
61
00G05701471
00G05701471
NUMBER-PLATE LIGHT
€41,94
62
AP8117258
AP8117258
VIBRATION-DAMPING RUBBER
€7,90
